S Series · Implant system

NobelReplace® S implant: the S Series version, explained

Tapered

The NobelReplace® S implant is part of the S Series. Its body in the bone is the same as the classic NobelReplace® CC implant; the difference is that every size has the same Narrow Platform (NP) conical connection.1

Request an assessmentRead the guide
Generic implants (not Nobel Biocare products)
In short
  • Body: tapered.1
  • Diameters 3.5, 4.3, 5.0 mm; lengths 8 – 16 mm.1
  • One NP conical connection for every size.1
  • TiUltra™ or TiUnite® surface.1

How it relates to the classic implant

The FDA summary states that the S Series implant bodies are the same as the predicate devices, so surgeons use the same drills and protocols they know from the classic NobelReplace® CC implant.1 What changes is the top: instead of NP, RP or WP connections by width, all sizes share one NP conical connection.

Regulatory record

The FDA 510(k) summary for the S Series (cleared 18 February 2026) describes one consistent diameter at the implant–abutment interface for every implant size and type: the Narrow Platform (NP) conical connection. 1

Classic NobelReplace® CC implantThe S Series family

Design in plain words

A tapered body that follows the shape of a natural tooth root. NobelReplace® implants have a long history in Nobel Biocare's range; the tapered conical connection version was cleared by FDA in 2006.2

Would you like a dentist to assess whether this treatment suits you?

Request an assessment

Sizes

Diameter (mm)Lengths (mm)Connection
3.58, 10, 11.5, 13, 16NP conical1
4.38, 10, 11.5, 13, 16NP conical1
5.08, 10, 11.5, 13, 16NP conical1

Nominal length is the label length; the manufacturer notes the true length differs slightly and surgeons plan with it.3

Good to know

The S Series is new (2026), so long-term clinical studies on these exact products do not exist yet. The body design has been used for many years in its classic form.

Which one is right for you? No website can answer that. The choice depends on your bone, the gap, the planned teeth and the surgeon's experience. Use these pages to prepare questions, not to pick an implant.

Frequently asked questions

Is the NobelReplace® S implant the same as the NobelReplace® CC implant?
Same body in the bone, different connection on top. The prosthetic parts are not the same.1
Why would a surgeon choose the S version?
The single connection simplifies parts and planning. The surgeon decides based on your case and what the clinic uses.
Clinical review pending. Facts on this page are checked against the sources listed below (regulatory records, manufacturer documents, peer-reviewed research). A named clinician will review it before we call it medically reviewed.
Last updated 28 Sep 2026 · How we review

Sources

  1. Regulatory recordFDA 510(k) K252197 — Nobel Biocare S Series Implants (510(k) summary) — U.S. Food and Drug Administration, 2026-02-18. Accessed 28 Sep 2026.
  2. Regulatory recordFDA 510(k) K062566 — NobelReplace Tapered Conical Connection — U.S. Food and Drug Administration, 2006-12-06. Accessed 28 Sep 2026.
  3. Manufacturer documentationNobel Biocare — S Series solution brochure (96387) — Nobel Biocare Services AG, 2026. Accessed 28 Sep 2026.

Educational information only. The choice of implant system depends on your anatomy, restorative plan, bone quality and the clinician's assessment. This website does not recommend a specific implant for you.
